TrueVIS XG-640 | Eco Solvent Printer | Large Format Printer Cutter

2 Year Trouble Free Warranty
Fastest Print Cut on Market: Faster then Mimaki or Epson 242sf/hr
More Configuration Options: CMYKOrGrWh or Dual CMYK
Best Value: XG-640 Cost less than the Epson S90600 and includes built in cutting.

Model: XG-640 64" Eco-Solvent Printer

$22,995.00 $25,995.00 Save $3,000

Overview Details Supplies Specs Instructions

Roland DGA has introduced the TrueVIS XG-640, a 64" professional eco-solvent printer/cutter engineered for speed, accuracy, and maximum profitability. Delivering more than double the productivity of the VG3-640, the XG-640 enables high-volume print shops to produce stunning vehicle wraps, decals, signage, floor graphics, and more with exceptional efficiency. Its dual staggered printheads achieve top speeds up to 819 sqft/hr, while new TR3 eco-solvent inks—available in dual CMYK or expanded 8-color options including Orange, Green, and White—deliver unmatched vibrancy. Combined with a user-friendly 7" touch panel, automatic media gap adjustment, and other advanced workflow features, the XG-640 sets a new standard for integrated printer/cutter performance.

TruVIS XG-640

64" | Eco-Solvent Printer/Cutter

Roland DGA launches the TrueVIS XG-640, a 64" professional eco-solvent printer/cutter built for speed, precision, and profitability. With more than double the productivity of the VG3, the XG-640 empowers busy print shops to deliver flawless results while maximizing return on investment. Its superior output, efficiency, and usability make it the go-to solution for vehicle wraps, decals, signs, floor graphics, and more.

Roland DG’s most productive integrated printer/cutter to date – nearly twice as fast as the VG3-640.
Advanced dual staggered printheads allow for top print speeds of up to 819 sqft/hr.
Exceptional vibrancy with new TR3 eco-solvent inks, available in dual CMYK or expanded gamut 8-color configurations including Orange, Green, and White options.
Enhanced usability with a 7-inch touch panel, automatic media gap adjustment, and other cutting-edge features designed to simplify operations.

Download Datasheet

Maximizing return on investment

Dual-purpose Performance

The Roland XG-640 is not just a printer—it’s a full-featured print-and-cut powerhouse. By combining wide-format printing and precision contour cutting in one seamlessly integrated device, it transforms how your workspace operates.

Fastest Print/Cut device in Class

The Roland DG TrueVIS XG-640 sets a new benchmark in the large-format eco-solvent printer/cutter category. It outpaces competitors such as the Mimaki JV330 Series and Epson SureColor S80600 with over 2X the output speed of Roland’s own previous-generation VG3-640—and delivers even greater speed advantages compared to other brands.

Roland DG Connect + Versaworks

Smart Software without monthly fees. Monitor your printer’s performance, ink usage, and job history in real time with the Roland DG Connect app. This cloud-based tool gives instant access to important operational data, helping print providers optimize productivity and reduce downtime.

TR3 Ink System

The Roland DG TrueVIS XG-640 excels with the fast-drying, GBL-free TR3 inks and high-opacity White, you’ll maximize uptime and finish jobs faster. Plus, with its ultra-wide color gamut and white
capabilities, the XG-640 outperforms latex and other solvent printers in one winning pass.

Pushing the Limits of Performance.

Unmatched Productivity and Precision Two larger staggered printheads eject finer ink droplets at higher densities for high-resolution output with fewer passes.

Intuitive 7” LCD Touchscreen A user-friendly control panel makes operation simple and efficient.

Print & Cut Precision Industry-leading technology with automated pinch rollers for seamless workflow and maximum productivity.

Versatile Applications Perfect for decals, vehicle wraps, signage, banners, floor and window graphics, backlit displays, wallpaper, posters, and more.

Smart Automation Advanced features like Automatic Media Gap Adjustment, which detects and adjusts media height to avoid head strikes and misprints.

Included VersaWorks 7 RIP Software Advanced color management with Nearest Color Finder and Variation Job functions.

Roland XG-640 Ink Configurations

Eight Color CYMK LC LM OR and GR

Super ULTRA Smooth Transitions

Seven Color CMYK OR GR WH WH

Four Color CMYK CMYK

Optimum Productivity

Getting to know the Roland XG-640

Roland XG-640 Specifications
Printing Method	Piezo ink-jet method
Media Width	13.2 to 64 in. (335 to 1,625 mm)
Media Thickness	Max. 39.3 mil (1.0 mm) with liner (printing) Max. 15.7 mil (0.4 mm) with liner / 8.6 mil (0.22 mm) without liner (cutting)
Roll Outer Diameter	9.8 in. (Max. 250 mm)
Roll Weight	Max. 99 lb. (45 kg)
Core Diameter	3 in. (76.2 mm) or 2 in. (50.8 mm)
Printing/Cutting Width	Max. 62.9 in. (1,600 mm)
Ink Type	Eco-Solvent Ink (TR3), 500 ml cartridge (white: 220 ml)
Ink Color Options	- 8-color: C, M, Y, K, Lc, Lm, Orange, Green - 7-color: C, M, Y, K, Orange, Green, White (x2) - 4-color: C, M, Y, K
Max Printing Resolution	1,800 dpi
Cutting Speed	0.39 to 11.8 in/s (10 to 300 mm/s)
Blade Force	30 to 500 gf
Blade Type	Roland CAMM-1 series blade
Blade Offset	0.0 to 59 mil (0.000 to 1.500 mm)
Software Resolution (Cutting)	0.98 mil/step (0.025 mm/step)
Media Heating System	Print Heater: 86–113°F (30–45°C) Dryer: 86–131°F (30–55°C)
Connectivity	Ethernet (100BASE-TX/1000BASE-T, auto-switching)
Power-Saving Function	Automatic sleep feature
Rated Input	100-120 / 220-240 V AC, 50/60 Hz, 8.9 / 4.5 A
Power Consumption	During Operation: Approx. 1,180 W Sleep Mode: Approx. 50 W
Acoustic Noise Level	Operating: ≤ 66 dB(A) Standby: ≤ 56 dB(A)
Dimensions (W × D × H)	113.7 × 29.5 × 55.8 in. (2,886 × 748 × 1,415 mm)
Weight	433 lb. (196 kg)
Operating Environment	Temp: 68–89.6°F (20–32°C), Humidity: 35–80% RH (no condensation)
Storage Environment	Temp: 41–104°F (5–40°C), Humidity: 20–80% RH (no condensation)
Included Items	Stand, power cord, media take-up unit, media holders, separating knife blade, maintenance liquid bottle, drain bottle, User's Manual, VersaWorks, Roland DG Connect, etc.
