Mimaki JFX600 Series Wide Format Flatbed Printer with high-speed production, large print areas, and eco-friendly UV-LED inks

Mimaki JFX600 Series UV Printer

High-Speed Production: Full board printing in under 60 seconds with print speeds up to 2152 ft²/hr.

Versatile Print Areas: Full bleed print areas of 8' x 4' and 8' x 10' for diverse printing needs.

Advanced Features: Easy on-board touch screen control and production workflow ready with IoT support.

Eco-Friendly Inks: Uses Greenguard Gold certified UV-LED inks for sustainable printing.

$189,000.00

Earn [points_amount] when you buy this item.

Overview Details Supplies Specs Instructions

High Performance, Extreme Efficiency

The JFX600 Series wide format flatbed printers offer high-speed production with full board printing in under 60 seconds. Featuring a quick registration system, semi-automated maintenance, and full board and extra-large print areas of 8’ x 4’ and 8’ x 10’, these printers are perfect for high-volume packaging, POP shops, as well as specialized architectural printing and interior design shops.

Key Features

  • 16 print heads
  • Print speeds up to 2152 ft²/hr (faster than 1 board per minute)
  • Easy navigation on-board touch screen control (MPC)
  • Industry-leading core technologies
  • Production workflow ready with IoT support
  • Eco-friendly Greenguard Gold certified UV-LED inks
  • PICT remote monitoring

Applications

JFX600-2513 Specifications

  • Full bleed 8’ x 4’ print area, up to 2.36” thick
  • Two selectable vacuum zones

JFX600-2531 Specifications

  • Extra-large full bleed 8’ x 10’ print area up to 2.36” thick
  • Nine selectable vacuum zones
  • Toggle-print continuous print functionality

Click the Details Tab for full specifications

Inks

Type Cyan Magenta Yellow Black White Clear Primer
LH-100 UV curable ink LH100-C-BA LH100-M-BA LH100-Y-BA LH100-K-BA LH100-W-BA LH100-CL-BA
UV curable ink (LUS-120) LUS12-C-BA LUS12-M-BA LUS12-Y-BA LUS12-K-BA LUS12-W-BA LUS12-CL-BA
UV curable ink (LUS-150) LUS15-C-BA LUS15-M-BA LUS15-Y-BA LUS15-K-BA LUS15-W-BA (Use LH-100)
UV Primer (PR-200) PR200-Z-BA

Resources

Know before you buy

JFX600-2513 Specifications - EN

JFX600-2531 Specifications - EN

JFX600 Series Brochure - EN

Ink Configurations:

LH-100

  • 4 Color - MMCCYYKK
  • 4 Color + White, Clear, Primer - MCYKWWClPr
  • 6 Color + White - MCYKLcmWW


LUS-120

  • 4 Color - MMCCYYKK
  • 4 Color + White, Clear - MCYKWWClCl
  • 4 Color + White, Clear, Primer - MCYKWWClPr
  • 6 Color + White - MCYKLcLmWW
  • 6 Color + White, Clear - MCYKLcLmWCl


LUS-150

  • 4 Color - MMCCYYKK
  • 4 Color + White, Clear - MCYKWWClCl
  • 4 Color + White, Clear, Primer - MCYKWWClPr
  • 6 Color + White - MCYKLcLmWW
  • 6 Color + White, Clear - MCYKLcLmWCl


LUS-190

  • 4 Color - MMCCYYKK
  • 4 Color + White, Clear - MCYKWWClCl
  • 6 Color + White - MCYKcLmWW

Items included with the Mimaki JFX600 Series UV Printer

JFX600-2513 Promo Bundle Includes:

  • Ionizer Bar: Ensure impeccable print quality by eliminating static electricity.
  • Installation Kit: Get your printer up and running smoothly with our comprehensive setup package.
  • Maintenance Kit: Keep your printer in optimal condition with essential maintenance tools.
  • 3L Bulk Ink System: Extend your printing capabilities with a high-capacity ink system.

mimaki lus-120 white ink product photo Mimaki LUS-120 1000ml UV Ink - 0

Mimaki LUS-120 1000ml UV Ink

$119.00
View
Mimaki LUS-150 1000ml Mimaki LUS-150 1000ml - 0

Mimaki LUS-150 1000ml

$241.00
View
PR-200 Ink Primer 1L Bottle

PR-200 Ink Primer 1L Bottle

$290.00
View
PR-200 Maintenance Liquid

PR-200 Maintenance Liquid

$37.00
View
Mimaki maintenance liquid for UV printers

Mimaki UV Maintenance Liquid 07 | 1L

$62.00
mimaki uv printer maintenance liquid washing liquid only Mimaki UV Maintenance Liquid 15 (100ml Bottle) - 0

Mimaki UV Maintenance Liquid 15 (100ml Bottle)

$37.00
View
Mimaki Maintenance Kit Mimaki Maintenance Solution

Mimaki Maintenance Liquid 15 Kit

$144.00
View

Printhead

Sixteen on-demand piezo heads in a staggered array

Print Resolutions

600 x 600dpi, 600 x 1,200dpi, 1,200 x 1,200dpi

Print Speed (4 Color Mode)

up to 2,152.78 SqFt/Hr (200.0 m2/h)

Maximum Print Area

JFX600-2513: 98.43″ x 51.18″ (2,500 mm x 1,300 mm)

JFX600-2531: 98.443″ x 122.05″ (2,550 mm x 3150 mm)

Maximum media area

JFX600-2513: 101.6” x 80.3”

JFx600-2531: 100.43″ x 124.05″

Maximum Media Thickness

up to 2.36″ (60 mm)

Maximum Media Weight

10 lb./ft2 (50 kg/m2)

Ink Type

Rigid: LH-100, Flexible: LUS-120, LUS-150

Interface

Ethernet 10,000 BASE-T

Power Supply

AC 200 – 240 V, 50/60 Hz

Power Consumption

Less than 4.8kWhr x3

Operational Environment

Temperature 68° – 86° F (15-30° C)
Humidity: 35–65 % RH (Non condensing)

Dimensions (W × D × H)

JFX600-2513: 207.48″ x 110.24″ x 62.99″ (5,300×2,850×1,700mm)

JFX600-2531: 213” x 191” x 67”  (5400mm x 4850mm x 1700mm)

Weight

JFX600-2513: 2,645.5 lbs. (1,200 kg)

JFX600-2531: 3,527 lbs. (1,600 kg)

Certifications

UL 775 ETL, CE Marking (EMC Directive,Low Voltage Directive, Machinery Directive), RoHS / REACH / EAC
