Z TIME OUT ERROR: Check the Hook Assembly for threads or, making sure that there are no threads in or behind the Hook. Remove the threads if any, and then go to the Head Timing Menu and do an ALT Up Arrow function, Go To Head Up. Check the hook...

X OR Y RACK NOT DONE: Oil the Pantograph as a first measure, if it hasn't been done lately, refer to the Operation Manual. Lubricating the EMC 10. Try Reconfiguring. Refer to the Operation Manual under "Configuring the EMC10" in the contents of the manual. Check all the X and...

THE NEEDLE CASE TRIES TO RUN OFF TO ONE SIDE OR THE OTHER WITHOUT CONTROL OR INDICATION OF A COLOR CHANGE: Check the Logic 5 Volts for proper setting. Refer to the Technical Manual. Make sure the Color Change PCB is pushed all of the way down on it's 4-mounting...

THE PANTOGRAPH UNLOCKS IN MID-SEW: Check to see if the garment has caught any part of the chassis, causing a stoppage. Any restrictive movement of the X or Y Axis will cause the Pantograph or the X Carriage to UNLOCK as if the motors are turned off. This is a...

THE PANTOGRAPH WILL NOT MOVE WHEN SETTING HOME: Check the Logic 5 volts as previously noted on page #1. Try reconfiguring the EMC 10 which may help delete error's that may be in the CPU's buffer. The 24 Volt side of the Power Supply may be non-functional. Check for 24...

THE COLORED THREAD PULLS OUT OF THE NEEDLE AFTER A TRIM CAUSING A THREAD BREAK: This error is caused by all of the information mentioned in the section before. Use the suggested tips to try to solve this problem. Check the Under Thread Presser as seen in the Technical Manual....

THE X OR Y AXIS OR BOTH WILL NOT MOVE WHEN TRYING TO SET HOME: Try powering the machine off, wait 20 seconds, and power on again. Try setting home again. Reseat the CPU & 4 Axis PCBs as outlined in the Technical Manual where it shows how to replace...

THREAD BREAKS: Needle Depth and Hook Timing should be checked first. Refer to Operation Manual for instructions how, and the specific settings to use. Replace the needles if they have not been changed recently. Constant use will dull the needle tips and needle eyes have been known to form burrs....

TRIMMER SYSTEM NOT TRIMMING THREAD (TOP OR BOBBIN): Check the Technical Manual to determine what part of the Trimmer System is causing the error. (Trimmer Option Section) Inadequate or too tight Thread Tensions can cause the trimmer system not to cut thread correctly. If the thread tension is too loose,...

WIDE ANGLE CAP FRAME (WACF): Cap Frame is binding, moving forward, back or side to side. Make sure Cap Supports or "Wings" are extended out far enough to allow for smooth movement. NOTE: There are new "Small Cap Supports" that come in a kit with part number 10868. They will...

Computer Driver Sequence Video - GH Audio - SCRZ Modem - 9C9 Nic - Z95

Error Codes REPLACE INK CARTRIDGE SOON Possible Causes The maintenance tank needs to be reset Possible Solutions Reset maintenance tank according to the instructions in the maintenance tank section. Possible Prevention Do not let the maintenance tank fall below 50%. Lights are flashing on the control panel Possible Causes Green...

Tools needed for installation: 2.5mm Metric Hex Driver 3mm Metric Hex Driver Needed Parts: Sleeve Table Adapter Plate Two (2) Short Table Interface Brackets Six (6) M4 Countersunk Hex Screws Installation Instructions Remove the Standard Frame Table from the machine. Loosen and remove the hardware – 4 screws – at...

Tools needed for installation: 2.5mm Metric Hex Driver 3mm Metric Hex Driver Needed Parts: Small Table Adapter Plate Two (2) Short Table Interface Brackets Six (6) M4 Countersunk Hex Screws Installation Instructions Remove the Standard Frame Table from the machine. Loosen and remove the hardware – 4 screws – at...

Tools needed for installation: 2.5mm Metric Hex Driver 3mm Metric Hex Driver Needed Parts: Polo Table Four (4) M4 Countersunk Hex Screws Installation Instructions Remove the Standard Frame Table from the machine. Loosen and remove the hardware – 4 screws – at each corner of the table using the 3mm...
