Support Articles

1) Remove Encoder Strip. Release spring on left side of printer (see Figure 1) ,then remove Encoder Strip from tab on right side of machine. Use two piecesof tape to secure metal tabs on the left end of the rails to the frame of themachine. 2) Move the wiper blade...

Epson R1900 Anajet Exploded Diagram Schematic

Waste ink is collected in the Waste Ink Tank located inside the printer below the Maintenance Station. When the Waste Ink Tank is full the printer will beep once and the LCD control panel will display the message WASTE INK FULL / PLEASE DRAIN. The Waste Ink Tank must be...

Diagnosis: When printing, the print appears correct on one side and fuzzy on another side or corner. Solution: You will need a level to make sure that all four corners of the Print Table are the samedistance from the Carriage Bar. To measure this, place your Gauge Block on the...

If when sending a print job to the printer, and before pressing the Print Button, the Control Panel LCDreads “DO NOT TURN OFF” (Fig. 1) and does not go away within a few minutes and appears to be frozen,this is the result of a scheduled Auto Maintenance attempting to initialize...

Ink may stop flowing in one or more lines for any of four reasons: (Note that a stoppage of ink flow is different from a restriction of ink flow. By “stoppage” this article means that Cleaning Solution cannot be drawn down one or more ink lines, not just that flow...

If when starting up the printer and pressing the Power Button the Control Panel reads “PLEASE WAITSYSTEM INITIALIZING” (Fig. 1)and does not go away within 5 minutes and appears to be frozen, thismeans that you have jobs in the print queue that need to be deleted before the printer can...

There are two ways to classify air in the Ink Tubes.The first scenario is air bubbles in the Tubes. If you have tiny air bubbles in the Tubes you can ignorethem. These bubbles will be smaller than the diameter of the Ink Tubes; they will not cause a problem.These tiny...

  Background: The Reset Service Counter message is a result of the Epson F-mach Print Head used in the AnaJet. Because the Print Head is used in several different types of printers, it tries to keep track of its usage. When the Print Head gets past a certain internal limit,...

Diagnosis: When printing, the Wait Light turns on and does not turn off.Solution: There are two things that can cause this type of problem. The first one is the most commonand should be tried first but if this does not correct the problem then try second step.  1) If wait...

Get a Replacement print head for your Anajet FP-125 to repair your Anajet sprint Caution: The Print head is very static sensitive, use antistatic protective equiment when working on it.  Before beginning this repair make sure the power is turned off at the back switch and the printer’s power cord...

Get a Replacement print head for your Anajet FP-125 to repair your Anajet sprint Caution: The Print head is very static sensitive, use antistatic protective equiment when working on it. 1 - Remove the Dampers. To avoid ink leaking, place dampers and tubes higher than the level of the ink...

Buy the Anajet Pump and Capping Station Watch a video on Removing the Anajet Sprint Pump and Capping Station Watch a Video on Installing the Anajet Sprint Pump and Capping Station Removing the Control Panel The LCD is very static sensitive, use antistatic protective equipment. Remove the two Phillips (+)...

DTG Kiosk II Training Understanding the Parts and Components1 DTG Kiosk II Training Understanding the Parts and Components 2
