 The settings will allow the user to control the spray density and spray length. 1. To adjust the settings, enter the Settings Menu by selecting the Settings Menu icon. 2. The Spray Density can be adjusted by pressing the Spray Density Setting and entering a value between(20 – 100). 3....

Priming the Pearl Elite is required for proper spray pattern on the garment. If the Pearl Elite is improperly primed, you may not get an even, flat and consistent spray pattern on the garment. 1. To prime the machine, enter the Maintenance Menu by selecting the Maintenance Menu icon. 2....

Home Menu 1. Start/Stop Button Press to start or stop spray cycle. 2. Light Pretreat Level Meter Displays estimated light pretreat remaining. 3. Dark Pretreat Level Meter Displays estimated dark pretreat remaining. 4. Garment selection Displays garment selection: light or dark garment. 5. Spray Length Area Displays spray length setting....

The Pearl Elite is powered with either 110V/60Hz or 220V/50z. Please check with distributor to verify the power requirements for the Pearl Elite in your region. 1. Plug the power cord in to the power connector located on the back of the Pearl Elite. 2. Press the Power Switch to the...

1. All Purpose Cleaner Used to clean the Pearl PTM after use. See “Keeping the Pearl PTM Clean” 2. Shop Rags or Towel Used to clean the Pearl PTM after use. See “Keeping the Pearl PTM Clean” 3. Distilled Water Used to clean the Pearl PTM after use. 4. Replacement Nozzle TEEJET...

  1. Nozzle Cap Secures Nozzle to Nozzle Body 2. NozzleProvides Even Spray Pattern 3. Rubber Seat Secures Nozzle in the Nozzle Cap 4. Check Valve Stops dripping from Nozzle after Spray Cycle Nozzle Assembly Place Nozzle(2) inside Nozzle Cap(1), then place Rubber Seat(3) inside Nozzle Cap(1) on top of...

    1. Touch Screen User InterfaceControl interface for the Pearl Elite. 2. Garment PlatenPlace garment to be treated on Platen. 3. Platen Height AdjustmentsAdjusts the height of the platen. 4. Platen DrawerPull open to load the garment. 5. Platen Drawer ReleaseReleases the Platen Drawer to remove the PlatenDrawer. 6....

  Your safety and the safety of others are very important. We have provided many important safety messages in this manual. Always read and obey all safety messages. This is the safety alert symbol. This symbol alerts you to potential hazards that can injure you or others. This symbol will...

Answer - This is due to the nozzle and/or check valve. The check valve is most likely the issue if it drips quite a bit. The nozzle would drip only one or two drops if it was bad. If it's the check valve it would stream out quite a bit...

Learn how to prepare a Brother GT-541 direct-to-garment DTG printer for long term storage.

Learn how to perform a nozzle check on the white ink channels on the Brother GT-782 direct-to-garment DTG printer. The nozzle check feature shows if all the nozzles in the four print heads are firing properly.

Learn how to manually clean the nozzles on the bottom of the print heads on the Brother GT-541 or GT-782 printers.

Learn how to perform a nozzle check on the Brother GT-541 direct-to-garment DTG printer. The nozzle check feature shows if all the nozzles in the four print heads are firing properly.

Learn how to remove and install the inline filters on the white ink lines on the Brother GT-782 printer.

Learn how to adjust the frequency to which the Brother GT firmware is set in order to wipe the bottom of the print heads with the wiper blade.

Learn how to thoroughly clean the wiper assembly arms on the Brother GT direct-to-garment DTG printers. When performing this level of cleaning, please make sure that you cover the caps with a paper towel to prevent pieces of dry ink from going into the caps.
