(1) Start at main menu, scroll down to "Maintenance". (2) Press OK. (3) Scroll down to "Nozzle Cleaning", Press OK; then follow instructions on the screen. (4) Open the front cover to inspect the maintenance parts. (5) Manually move the carriage to give your room to inspect the nature. (6)...

Key Pad Function Panel LCD Description Push either one of the OK Button, Up Button and Back Button to go into the Menu.

(1) Turn on the GT-3. (2) On the control panel, press the Up/Down Button and select maintenance, press okay. (3) Select "Nozzle Cleaning", press okay. (4) The platen will move out and in, the caps will drop and the carriage move to the right. (5) The screen will prompt you...

There are several maintenance procedures that must be performed on a daily, weekly, or prompted basis to help keep your printer performing properly. Some of these procedures are required for the printers with white ink (GT-361, GT-381). High production volume may alter the frequency of some maintenance procedures. This guide...

<Note>Confirm that the waste tube is not submerged in the waste ink tank before executing any maintenance.    White Agitation to save on waste (Firmware ver. 3.00 or higher) You can save the waste of the White Ink by moving the Carriage with [White Agitation] menu. You can keep the...

(1) Open the printer. (2) Unscrew the knob on the felt supports and remove them. (3) Remove and replace the felts on the bottom of the felt supports in accordance with the "Maintenance Parts Exchange". (4) Take an isopropyl swab or cloth (95% or higher) and clean the rail thoroughly....

(1) Make sure the GT-3 is not in the middle of any operation and is turned off. (2) Gently twist the nut (counter clockwise) on the tube to remove it from the top portion of the white filter (same filter as the GT-782). Be careful of any ink spilling out....

It is recommended to change the platen sheet when it starts to crack, tera or peel. The Platen Sheet becomes dirty with inks and garment lint within time from use and operation. This actually helps the garments being printed to lay and hold flat on the platen when printing. You...

The Wiper Cleaner needs to be replaced regularly. Keep the Print Head Cap and Wiper Blade clean when replacing the Wiper Cleaner. If not, the waste ink may drop on a T-shirt in printing or mis-firing may not be easily improved. (1) With power on, press the platen eject button...

(1) Power on the machine and Eject the Platen. (2) Power off the machine. (3) Open the front cover/lid. (4) Locate the Fan inside the printer. Grasp the side of the fan cover facing the rear and pull the cover away from the fan toward the left side of the...

(1) Select encoder strip cleaning from the maintenance menu on the panel, and follow the prompts ending with turning the machine off. (2) Loosen the four black thumb screws (do not remove) on the encoder cover, and remove the cover. (3) Slide the carriage to the right side of the...

(1) Take a print head out of GT-541. This work should not be done on the heads still mounted on the printer. Prevent ink spills over the printer. (2) Take the filter off and intake the air. (3) As the photo shows put the air into the head and drain...

(1) Seal the hole on the Filter Cartridge with adhesive tape, etc. (2) Replace the Waste Ink Cartridge. (3) Make sure GT-541 is not in the middle of any operation. (4) On the Control Panel, press the Platen Button to eject the Platen if it is not. (5) Press the...

Description: Actuates the Maintenance unit by using the sequence of measuring the pump pressure and clears any clogs and obstruction in tubes below Head Caps. Steps to accomplish and determine if clog occurs Please do not attempt this step until you have done a cap wiper cleaning, checked the wiper caste...

(1) Remove Back Cover.       Unscrew 15 screws of Back Cover. Unscrew 1 screw pan at the body edge of Ground Wire: 220, Open Front Cover and raise Rear Cover from the bottom. (2) Remove the five screws bind (M4x8) (in the red circles shown below), and then...

6-1-7. Replacing the Maintenance Unit Refer to "6-2-11. Replacing Maintenance PCB" when you replace Maintenance PCB. Preparation (1) Make sure GT-541 is not in the middle of any operation. (2) Press the OK Button on the Control Panel to open the Menu Display. (3) Press the Up/Down Button to select...
