Support ArticlesDTG

6-2-7. Replacing Control Box When the PCBs inside are replaced, use GTService Tool to readjust firmware controls. Prepare a voltmeter (tester) and a thermometer and refer to the pages concerned. (1) Remove Power code. (2) Remove Operation Panel.      Remove 4 screws at both sides. Unscrew the Print SW...

7-1. Removing the Covers The following describes how to remove the Covers. (1) Rotate the Print Button Cover counterclockwise to remove it. (2) Remove the four screws truss (M4x6) (shown in the picture below), and then remove the Control Panel. (3) Turn over the Control Panel Cover, and then disconnect...

7-3. Disassembling the Control Panel (1) Rotate the Print Button Cover counterclockwise to remove it. (2) Remove the four screws truss (M4x6) (shown in the picture below), and then remove the Control Panel. (3) Turn over the Control Panel, and then disconnect the Flat Cable from the Pancel PCB. The...

6-1-3. Replacing the Tubes The Tubes can be replaced for every color. The following procedure shows the example of replacing the Tube for "Cyan." The procedure is the same for other colors. (1) Make sure GT-541 is not in middle of any operation. (2) Press the OK Button on the...

6-1-4. Replacing the Needles The Needle can be replaced for every color. The following procedure shows the example of replacing the Needle for "Cyan." The procedure is the same for other colors. (1) Make sure GT-541 is not in middle of any operation. (2) Press the OK Button on the...

6-1-6. Replacing the Tube Pump Tubes of the Maintenance Unit (1) Turn off GT-541 (2) Remove the Rear Cover     (See "7-1. Removing the Covers" for details.) (3) Disconnect the Pump TUbe on the top left of the Tube Pump connected with the Drain Plug. (4) Pull out the L-shaped...

6-1-12. Replacing the Cap Rubbers (1) Make sure GT-541 is not in middle of any operation.  (2) Press the OK Button on the Control Panel to open the Menu Display. (3) Press the Up/Down Button to select "Maintenance", and then press the OK Button. (4) Press the Up/Down Button to...

There are many reasons why one day you could be getting great white prints and the next it starts fading or banding or not coming out at all. It would be a mistake to jump the gun and assume it's a clog. Many time there is a pressure issue. Either...

To remove the print head on your Epson F2000 and F2100,  Remove the damper unit (4 screws on either side)Remove the black clip on the rightPull damper unit out and disconnect the ribbons  Now you will see the head which is held by 3 screws One is obvious and the...

Watch this video to learn how to open up your existing Brother GT 361 381 ink cartridge and replace it with our GPI Replacement ink bag.

Imaging Solutions for Direct To Garment Printing to Save Money and Improve Quality iProof's DTG RIPPRO v06 for the Epson SureColor F2000 A versatile RIP offering features not found in Garment Creator or other RIPs. RIPPRO reduces ink costs up to 50% offering more white ink control than other RIPs...

There are many reasons you may get the "white screen of death" on your Anajet mPower printer, however it is often when attempting to flash the firmware or after sending hundreds to thousands of designs to your printer to print. It's really important to actually Format the SD card rather...

Changing an Ink Cartridge The ink indicator on the Display flashes when the Ink Cartridge is getting low. Prepare the new Ink Cartridge (option*), and replace it when “Empty XXXX (color)” is displayed.  Make sure to replace the Ink Cartridge indicated on the display.  Be careful not to...

Adjusting the Platen Height Under the Platen 1 Platen Fixing Lever Fixes the Platen Tighten/Loosen this lever to install/uninstall the Platen and to adjust the Platen height. Move the Platen Height Adjustment Lever(2) to the A position in the right image and loosen the Platen Fixing Lever (1). When you...
